Heavy Duty Pallet Rack
Bolted pallet racking for warehouse and distribution storage. Xinyuan’s heavy duty pallet rack uses Q235 steel uprights and box-beam or step-beam levels, giving load capacities up to 4,000 kg (8,800 lb) per level. Frames are roll formed in-house, powder coated, and shipped knocked-down to keep container costs down.
Key Features
- Frame capacity up to 4,000 kg (8,800 lb) per beam level
- Upright heights from 2,000 mm to 12,000 mm (79 in to 472 in)
- Teardrop (common) or slotted upright profiles, 76 mm / 90 mm / 100 mm (3 in / 3.5 in / 4 in) pitch
- Box beam and step beam options, safety locking pins as standard
- Powder coated finish in any RAL colour; hot-dip galvanised for cold or wet environments
- Compatible with wire decking, steel panels and pallet support bars
Specifications
- Material: Q235 structural steel
- Upright section: 80×60 mm to 120×95 mm (3.1×2.4 in to 4.7×3.7 in), 1.5–2.5 mm (0.06–0.10 in) wall
- Beam section: 80×50 mm to 140×50 mm (3.1×2.0 in to 5.5×2.0 in)
- Load per level: 1,000–4,000 kg (2,200–8,800 lb)
- Frame depth: 800–1,200 mm (31–47 in); beam length: 1,200–3,600 mm (47–142 in)
- Finish: electrostatic powder coating, 60–80 μm
- MOQ: 1,000 pcs (mixed sizes accepted)
Applications
- Warehouses and distribution centres
- Third-party logistics (3PL) facilities
- Manufacturing plants and raw material stores
- Cold storage (galvanised option)
Get a Quote
Tell us your required size, load per level and target quantity — we reply with a factory-direct quotation within 24 hours. OEM and ODM orders welcome.
